Pipe Spiral
Thickness : 0.125 - 1.58 inch
Section Shape : Round Outer
Diameter : 8 - 160 inch
Place of Origin: Indonesia
Secondary or Not : Non-secondary Application: Steel Pipe Piles, Line Pipe, Water, Etc
Technique : SAW
Certification : API
Alloy or Not : Non-alloy
Material : Gr.1, Gr.2, Gr.3
Standart : ASTM A252
Catogory: Steel Pipe Piles
Specifications :
Steel Spiral Pipe Piles
1) ASTM A252 GR1, GR.2, GR.3
2) Spiral Steel Pipe Piles
3) Helical SAW
4) Piling pipe
SPIRAL STEEL PIPE PILES
Usage : Used for steel pipe piles foundation in port , terminal and Bridge construction.
Process:
SMLS ( Seamless Steel Pipe)
ERW ( Electric Resistence Welded, Flash werded, Fusion Welded)
SAW ( Submerged-arc Welded)
HSAW ( Helical Submerged-arc Welded)
LSAW ( Longitudinal welded steel pipe)
Specification:
Seamless Steel Pipe:
Specification: Outer Diameter
Hot finish: 2 " - 30 " ,
Cold drawn: 0.875 " - 18 "
Wall Thickness: Hot finish: 0.250 " - 4.00 " Cold drawn: 0.035 " - 0.875 "
Length: customizing
Welded Steel Pipe:
ERW/ HFW, SAWL, SSAW/ SAWH
Specification:
Outer Diameter: 6mm-3520mm( 1/ 16” -84” )
Wall Thickness : 0.3mm-45mm
Length : 6mtr – 12mtr
Quality Standard & Steel Grade :
Executive Standard: ASTM A 252, ASTM A53
Material : Gr1, Gr 2, Gr3, GrA, GrB, GrC
Test :
Chemical Component Analysis, Mechanical Properties ( Ultimate tensile strength, Yield strength, Elongation) , Technical Pr operties ( Flattening Test, Bending Test, Blow Test, Impact Test) , Exterior Size Inspection
